CIP System

Full-auto Clean-In-Place system for dairy, juice, beverage and brewery lines. Configurable acid, alkali, hot-water and cold-water cleaning circuits with Siemens PLC control and Schneider electrical components.

Quick Specifications

Model: HTK-QX-01
Capacity: 1,000 – 30,000 L/h
Material: SUS 304 (SUS 316L optional)
Voltage: 220/380/415/440 V · 50/60 Hz
MOQ: 1 unit
Lead time: 45 – 60 days
Warranty: 12 months

Get Quote on WhatsApp · Reply < 2h Email for Detailed Spec Sheet

In stock CE / ISO certified FOB Shanghai

§ Description

Detailed description

HTK manufactures high-quality CIP systems for dairy, fruit-juice and beverage production lines. The system handles the full cleaning cycle after production: acid clean → alkali clean → hot-water rinse → cold-water rinse. Procedure sequencing is fully programmable to your line's requirements, with full-auto, semi-auto and manual control modes.

All product-contact piping is internally polished to a sanitary finish to ensure full self-cleaning and self-sterilization, removing any risk of cross-contamination between batches. The unit includes its own electrical distribution cabinet built with Siemens PLC and Schneider components, controlling tank temperature, discharge temperature, acid/alkali concentration, flow rate, fault alarms and procedure shifting.

§ Standard Components

What's in the box

→Siemens PLC + touch screen HMI
→UK Spirax Sarco steam-pressure reducing & drain system
→Germany temperature inspection & regulation
→JUMO conductivity meter (Germany)
→Contrinex / IFM flow-rate switch
→Pneumatic diaphragm pump (Germany)
→Pneumatic butterfly valves
→SUS 304 electrical distribution cabinet

§ Why this model

Energy efficient
Auto-recycling of cleaning solutions reduces water and chemical consumption by up to 35 % vs manual cleaning.
Long service life
All wetted parts in food-grade SUS 304/316L. Average operational life 15+ years with normal service.
Simple maintenance
Modular design — swap pumps, valves and sensors without taking the line down for more than 30 minutes.
Custom procedures
Cleaning sequence is fully reprogrammable as your production needs evolve.

§ Technical Parameters

Sizing options at a glance

Sub-model	Capacity	Tank Volume	Power	Steam	Footprint
QX-01-1K	1,000 L/h	2× 500 L	5.5 kW	120 kg/h	2.5 × 1.8 m
QX-01-3K	3,000 L/h	3× 1,000 L	11 kW	280 kg/h	3.5 × 2.2 m
QX-01-5K	5,000 L/h	3× 2,000 L	15 kW	450 kg/h	4.2 × 2.5 m
QX-01-10K	10,000 L/h	4× 3,000 L	22 kW	800 kg/h	5.5 × 3.0 m
QX-01-20K	20,000 L/h	4× 5,000 L	37 kW	1,400 kg/h	7.2 × 3.5 m
QX-01-30K	30,000 L/h	4× 8,000 L	55 kW	2,200 kg/h	9.0 × 4.0 m

All dimensions approximate — final layout depends on plant constraints. Custom sizes available.
